Kontron KTQ45/Flex - IO Map

KTD-00782-H KTQ45 family Page 56 of 92
5.4 IO Map
Address range (hex)
Size
Description
0
000F
16
DMA-controller
0
0CF7
3320
PCI-bus
10
001F
16
Motherboard resources
20
21
2
Programmable interrupt controller
22
003F
30
Motherboard resources
40
43
4
System timer
44
005F
28
Motherboard resources
60
60
1
Standard keyboard
61
61
1
System Speaker
62
63
2
Motherboard resources
64
64
1
Standard keyboard
65
006F
11
Motherboard resources
70
71
2
System CMOS/Real time clock
72
007F
14
Motherboard resources
80
80
1
Motherboard resources
81
83
3
DMA-controller
84
86
3
Motherboard resources
87
87
1
DMA-controller
88
88
1
Motherboard resources
89
008B
3
DMA-controller
008C
008E
3
Motherboard resources
008F
008F
1
DMA-controller
90
009F
16
Motherboard resources
00A0
00A1
2
Programmable interrupt controller
00A2
00BF
30
Motherboard resources
00C0
00DF
32
DMA-controller
E0
00EF
16
Motherboard resources
00F0
00FF
16
Numerical Data Processor
170
177
8
Secondary IDE-channel
01F0
01F7
8
Primary IDE-channel
274
277
4
ISAPNP read data port
279
279
1
ISAPNP read data port
02F8
02FF
8
Communications port (COM2)
376
376
1
Secondary IDE-channel
378
037F
8
Printer Port (LPT1)
03B0
03BB
12
Intel(R) Q45/Q43 Express Chipset
03C0
03DF
32
Intel(R) Q45/Q43 Express Chipset
03F6
03F6
1
Primary IDE-channel
03F8
03FF
8
Communications port (COM1)
400
041F
32
Intel(R) ICH10 Family SMBus Controller - 3A60
04D0
04D1
2
Motherboard resources
500
057F
128
Motherboard resources
800
087F
128
Motherboard resources
0A00
0A0F
16
Motherboard resources
0A10
0A1F
16
Motherboard resources
0A79
0A79
1
ISAPNP read data port
0D00
FFFF
62208
PCI-bus
BC00
BC0F
16
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
C000
C00F
16
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
C080
C083
4
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
C400
C407
8
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
C480
C483
4
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
C800
C807
8
Intel(R) ICH10 Family 2 port Serial ATA Storage Controller 2 - 3A06
CC00
CC1F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A66
D000
D01F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A65
D080
D09F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A64
D400
D41F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A69
D480
D49F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A68
D800
D81F
32
Intel(R) ICH10 Family USB Universal Host Controller - 3A67
D880
D89F
32
Intel(R) 82567LM-3 Gigabit Network Connection
DC00
DC07
8
Intel(R) Q45/Q43 Express Chipset
E000
EFFF
4096
Intel(R) ICH10 Family PCI Express Root Port 5 - 3A78
EC00
EC1F
32
Intel(R) 82574L Gigabit Network Connection
FF90
FF9F
16
Intel(R) ICH10 Family 4 port Serial ATA Storage Controller 1 - 3A00
FFA0
FFAF
16
Intel(R) ICH10 Family 4 port Serial ATA Storage Controller 1 - 3A00
