6.6.4 Advanced settings – Configure Win627DHG Super IO Chipset
BIOS SETUP UTILITY
Advanced
Configure Win627DHG Super IO Chipset
Allows BIOS to Select
Serial Port1 Base
Addresses.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Serial Port3 Address [Disabled]
RS485 Port Address [Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Feature
Options
Description
Serial Port1 Address
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Select the BASE I/O address and IRQ.
(The available options depend on the setup for the
other Serial Ports).
Serial Port2 Address
Disabled
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Select the BASE I/O address and IRQ.
(The available options depend on the setup for the
other Serial Ports).
Serial Port2 Mode
Normal
IrDA
ASK IR
Select Mode for Serial Port2
If IrDA or ASK IR:
IR Duplex Mode
Full Duplex
Half Duplex
IrDA communication selection
Parallel Port Address
Disabled *
378
278
3BC
Select the I/O address for the Parallel Port.
Parallel Port Mode
Normal
Bi-Directional
ECP
EPP
ECP & EEP
Select the mode of operation for the Parallel Port
If ECP Mode:
ECP Mode DMA Channel
DMA0
DMA1
DMA3
Select a DMA channel in ECP mode of operation
If EPP mode:
EPP Version
1.9
1.7
Select version of EPP in the EPP mode of operation
Parallel Port IRQ
IRQ5
IRQ7
Select a IRQ for the Parallel Port
(Continues)
