Kontron KTQ45/Flex - Page 23

KTD-00782-H KTQ45 family Page 23 of 92
DOS Idle, Mean, No external load
Supply
Current draw
Power consumption
+12V
1.59A
19.08W
+5V
1.39A
6.95W
+3V3
1.28A
4.224W
-12V
-
0W
5VSB
-
0W
Total
30.254W
Windows XP, mean
3DMARK2001 (Game 1 – Car Chase test ) & 2 x CPUBURN
Supply
Current draw
Power consumption
+12V
3.16A
37.92W
+5V
1.55A
7.75W
+3V3
2.8A
9.24W
-12V
0.00A
0W
5VSB
0.00A
0W
Total
54.91W
S1 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0.76A
9.12W
+5V
1.11A
5.55W
+3V3
1.14A
3.762W
-12V
0.00A
0W
5VSB
0.00A
0W
Total
18.432W
S3 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0.00A
0W
+5V
0.00A
0W
+3V3
0.00A
0W
-12V
0.00A
0W
5VSB
0.21A
1.05W
Total
1.05W
S4 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0.00A
0W
+5V
0.00A
0W
+3V3
0.00A
0W
-12V
0.00A
0W
5VSB
0.21A
1.05W
Total
1.05W
