= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST ELECTRONIC COMPONENTS
CODE DESCRIPTION REF. Q.TY
GRA0002134 MAIN FILTER MK LD1 1
GRA0002138 HEADPHONE BOARD LD2 1
GRA0002165 MAIN BOARD MB 1
GRA0002166 MOTOR AND SUPPLY BOARD LD1 1
GRA0002167 LEFT PANEL BOARD UD1 1
GRA0002168 RIGHT PANEL BOARD UD1 1
GRA0002169 RIBBON CONTROL BOARD JG 1
GRA0002170 DISPLAY FRAME BOARD DG 1
GRA0002171 DISPLAY INTERFACE BOARD DG 1
GRA0002172 SOUND CONTROL BOARD JG 1
GRA0002174 SPEAKER SYSTEM CONNECTION BOARD UD2 1
GRA0002177 INTERNAL USB KEY BOARD OU 1
GRA0002183 61 KEYS KEYBOARD INTERFACE MK 1
GRA0002185 FRONT USB BOARD UD1 1
GRA1002101 128MBYTE SDRAM EXB SODIMM 144
WARNING (click here)
MB 1
GRA1002132 IN/OUT BOARD LD1 1
PART LIST GRA0002134 MAIN FILTER
CODE DESCRIPTION REF. Q.TY
BOB0001001 FERRITE RT250-150-120-K5B 1
BOB0005001 BOBINA VK200 2,0 SPIRE 4
CAV0010103 RILANCIO TERRA FILTRO RETE PA3X 1
CON0010019 CONN. M. VER. PTH, 1 FILE, 3 VIE, 3,96MM, B3P-VH-K, JST 1
INT0001012 INTERUTTORE RETE SS-160-7-A 1
INT0001013 PRESA RETE DA CST F FLAT EAR 1
PLA0001057 COLLARE IN NYLON N16B RICHCO 1
PLA0010177 SUPPORTO FERRITE RICHCO 4
VTA0001006 VITI 3MX14TC NERE 1
VTA0001023 DADI M3 AUTOBLOCCANTI 1
VTA0001048 RONDELLA 3X9X0.8 BIANCHE 1
PART LIST GRA0002138 HEADPHONE BOARD
CODE DESCRIPTION REF. Q.TY
BOB0005001 BOBINA VK200 2,0 SPIRE 2
CON0010015 CONN. M. VER. PTH, 1 FILE, 4 VIE, 2,5MM, B4B-EH-A, JST 1
CON0010058 PRESA STEREO 6.3MM JACK NRJ6HH 1
PLA0010177 SUPPORTO FERRITE RICHCO 2
