= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST GRA0002171 DISPLAY INTERFACE BOARD
CODE DESCRIPTION REF. Q.TY
BOB0001010 FERRITE EMI BLM21PG221SN1 4
BOB0001019 FILTRO EMI NFM21PC105B1C3 MURATA 2
BOB0001029 BOBINA SCHERMATA SMD 33UH 1,7A TSB74-330M-A 1
BOB0005004 ARRAY IND.BLA31AG102SN4D SMD 1
BOB0005005 FERRITE EMI BLM18BD102SN1D 2
CIN0010070 DC/DC CONVERTER WHITE LED DRIVER TPS61165 1
CON0010060 CONN. F. OR. SMD 1 FILE 4 VIE 1MM 04FMS-10SP-TF 1
CON0010086 CONN. 33X0.5 ZIF NORMAL TYPE 33FLZ-SM2-TB JST 1
CON0010087 CONN. M. OR. SMD 2X3.5MM SM02B-BHSS-1-TB JST 1
CON0010140 CONN. SMD JST 50 VIE 0.5 MM ZIF 1
CON0010141 CONN. F. OR. SMD 10 VIE 1MM 10FMS-10SP-TF 1
DIX0010013 SCHOTTKY DIODE MBR0540T1G 0,5A 40V 1
PART LIST GRA0002172 SOUND CONTROL BOARD
CODE DESCRIPTION REF. Q.TY
CON0010143 CONN. M. VER. SMD 2 FILE 8 VIE 1.27MM MICS/SMD 08 LUM. 1
INT0010004 PULSANTINO SWITCH SMD ALPS SKHMQLE010 3
LED0010007 LED SMD 1206, AMBRA, KPTD-3216SECK KINGBRIGHT 3
PART LIST GRA0002174 SPEAKER SYSTEM CONNECTION BOARD
CODE DESCRIPTION REF. Q.TY
CON0010014 CONN. M. OR. PTH, 1 FILE, 3 VIE, 2,5MM, S3BEH, JST 1
CON0010100 CONN. M. OR. PTH, 1 FILE, 3 VIE, 3,96MM, B3PS-VH, JST 1
CON0010147 CONN. 6 CONTATTI PRECI-DIP 1
VTA0001049 VITI 2,2X6,5 TC NERE 2
PART LIST GRA0002177 INTERNAL USB KEY BOARD
CODE DESCRIPTION REF. Q.TY
CON0010009 PRESA USB TYPE A 1
CON0010035 CONN. M. VER. PTH, 1 FILE, 7 VIE, 2,5MM, B7B-EH-A, JST 1
PART LIST GRA1002101 128MBYTE SDRAM EXB SODIMM 144
CODE DESCRIPTION REF. Q.TY
CIN0003043 IC.SDRAM 16MX16 MT48LD16M16A2P-75 :D TSOP54 4
REY0006002 RETE ARRAY 22E 0603X4 SMD 20
