Korg PA3X User Manual

267
Technical specifications
Appendix
Specifications and appearance are subject to change without notice for improvement.
Pads 4 + Stop button
Compatibility i-Series: Styles (some adjustments may be needed); Pa-series: Style, Perf., Sound, Song, Song Book
Operating System OPOS (Objective Portable Operating System), RX (Real eXperience) , DNC (Defined Nuance Control), Multitasking system,
Load while play feature, Upgradable, Self-Refresh Battery for PCM data, Internal clock
DATA STORAGE
Hard Disk Standard 4GB USB memory – Optional Hard Disk with the HDIK-2 kit
DVD-CD Player / Floppy Disk Optional using standard USB DVD/CD/FD Drives connected via USB Host ports
USB Ports for Memory Devices Yes (2 slots - 1 Host Rear, 1 Host Front)
USER INTERFACE
Display
320 × 240 TFT Graphical Color Touch Screen Display, with
Motorized Lift System
320 × 240 TFT Graphical Color Touch Screen Display
Controls Joystick - Ribbon - Dial - Up/+, Down/- - Tempo +/-
Programmable Controls 3 Switches - 8 Sliders - MP3 Volume/Drawbars Sliders
Cursors Real Time: Master Volume - Accompaniment/Player/Real Time Volume Balance - X-Fader
Switches Transpose, Memory, Bass Inversion, Manual Bass, Fade, Tap, Synchro, Ensemble, Auto Fill, Real Time Track controls, Tempo
Mic Settings Mic Volume, Harmony/Double Level, Delay/Reverb Level, Mic On/Off, Harmony On/Off, Double On/Off
Help System Context-Sensitive Multilanguage Hypertext
CONNECTIONS
MIDI IN - OUT - THRU
USB 2 Host (2.0 Hi Speed) and 1 Device (1.1 Full Speed)
Outputs 4 Analog Balanced/Unbalanced (Left/Right/Out1/Out2), 1 Digital (S/PDIF 48kHz)
Inputs 3 Inputs: 1 Mic XLR/jack combo connector with gain control and +48V Phantom Power - 2 Balanced/Unbalanced Line jacks
Headphone 1 Front jack connection
Pedals 1 Damper - 1 Assignable Footswitch/Pedal - EC5
Power Supply AC - Universal Voltage
ACCESSORIES
Supplied Accessories Manual, AC Power Cable, Music Stand, Accessory Disk
OPTIONS
Amplification and Speakers Pa AS - Pa Amplification System for Pa3X; 3 Channel Amplification System; 2x20 Watt (Middle/High Frequency) + 1x40 Watt
(Sub Woofer); 5 Speakers: 2 Middle range (80 mm) + 2 Tweeters + Dual Coil Subwoofer (130 mm); Aluminum case with Bass
Reflex System; Extremely Simple Connection - Power and the audio signal from the Pa3X are via a special connector that is
automatically attached to the keyboard. No Cable, No Power supply needs to be attached to the Pa3X
Dimensions (W x D x H): 992 x 173 x 137 mm / 39.06 x 6.81x 5.39 inch
Weight: 5.7 kg / 12.57 lbs
USB Memory Yes
CD / FD Through USB Host
Sampling RAM 256 MB Sampling Memory Board EXB-M256. The actual Sample memory varies depending on PCM compression.
Video Interface Graphic Video Interface VIF4 - NTSC/PAL board
Expression/Volume Pedal Korg EXP-2 - Korg XVP-10
Multi-Switch Pedal Korg EC5
Damper Pedal Korg DS-1H, DS-2H (both upporting half-pedaling)
Switch Pedal Korg PS-1
PHYSICAL DATA
Consumption Normal operation with no PaAS speakers: 35 Watt - Normal operation with PaAS speakers: 50 Watt (max) - Standby not
recharging: 1 ~ 1.5 Watt - Standby recharging: 7 ~ 9 Watt
Dimensions (W × D × H)
1192 x 366 x 145 mm / 49.93 x 14.41 x 5.71 inch without
music stand and with the display fully lowered
980 x 366 x 145 mm / 38.58 x 14.41 x 5.71 inch without music
stand
Weight 17.5 kg / 38.58lbs 14.7 kg / 32.4 lbs
KORG Pa3X Features 76-key Model 61-key Model

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
