Korg PA3X User Manual

= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST GRA0002165 MAIN BOARD
CODE DESCRIPTION REF. Q.TY
BOB0001010 FERRITE EMI BLM21PG221SN1 4
BOB0001019 FILTRO EMI NFM21PC105B1C3 MURATA 20
BOB0001026 BOB SCHERMATA SMD 15UH TSB127-150M 4.5A 2
BOB0001030 BOBINA 3.3UH 2.6A TRIGGER TSB74-3R3M 2
BOB0001031 BOBINA SCHERMATA SMD 5UH TSB74-5R0M-A 1
BOB0005002 FERRITE EMI BLM21B102SPT 8
BOB0005004 ARRAY IND.BLA31AG102SN4D SMD 7
BOB0005005 FERRITE EMI BLM18BD102SN1D 29
CIN0002040 CIRC.INT.NJM4580M OP.AMP. 5
CIN0002074 CIRC.INT. SN74 LVC 125A QUAD BUFFER 3-STA 1
CIN0002075 DSP TG01 MB87M4080PB-G (KORG INC) 1
CIN0002076 USB DEVICE TRANC. USB1105RGTR (NXP ISP1105BS) 1
CIN0002077 INT. SYSTEM PROCESSOR MC9328MX1VM20 1
CIN0003043 IC.SDRAM 16MX16 MT48LD16M16A2P-75 :D TSOP54 2
CIN0004005 RES.GEN.3,3V ETC811SUC 1
CIN0010003 INTERF. USB HOST CONTR., ISP1761, LQFP128 1
CIN0010027 OPTOISOLATORE PC410LENIP-OF, SOP6 1
CIN0010034 HEX SCHMITT TRIG. INV. SN74LV14APWR, TSSOP14 1
CIN0010035 HEX.UNB. INV. SN74AHCU04PW, TSSOP14 1
CIN0010036 DUAL D- FLIP FLOP.SN74LVC74APWR, TSSOP14 2
CIN0010037 SDRAM, 64MBIT, 16BIT, K4S641632K-UC75, SSOP54 4
CIN0010038 QUAD 2 IN AND GATE, SN74ALVC08PWR, TSSOP14 2
CIN0010039 SINGLE 2 IN AND GATE, 74LVC1G08DCK, DCK5 1
CIN0010041 NOR FL,16MBIT,16BIT,MX29LV160CTTC-70G, TSOP48 1
CIN0010043 1 OF 2 DEMUX SN74LVC1G18DCKR 1
CIN0010046 DSP TI TMS320C6726BRFP266 HTQFP 1
CIN0010052 CIRC.INT. SN74AHCT138PW SMD 1
CIN0010060 PSOC UC CYPRESS CY8C27443-24PVXI SSOP28 1
CIN0010061 CONV. D/A DUALE, 24BIT, DR118DB, TI PCM4104,TQFP48 1
CIN0010062 STEREO 24 BIT ADC 118DB DR TI PCM4202 1
CIN0010063 DUAL DC-DC CONV. ADJ 3A TPS54386PWP 1
CIN0010069 ONE GATE OR SN74LVC1G32DCK 2
CIN0010073 8BIT BID.BUFF.W TRIS.SER.RES SN74LVCR2245APW 5
CIN0010074 SILICON SERIAL NUMBER DS2411R+ 1
CIN0010075 2CH USB POWER SW. 0,25A-0,5A TPS2046BD, SOP8 1
CIN0010082 IC.SDRAM 32MX16 MT48LC32M16A2P-75 :D TSOP54 4
CIN0010083 DSP56724 250MHZ 144TQFP 1
CIN0010084 74LVC2G02 DUAL 2-INPUT NOR GATE 1
CIN0010085 74LVC2G08 DUAL 2-INPUT AND GATE 1
CIN0010086 74LVC2G32 DUAL 2-INPUT OR GATE 1
CIN0010087 74LVC573A OCTAL TRANSPARENT D-LATCH 3
CIN0010089 TPS62410 2.25MHZ 2X800MA DUAL STEP DOWN CONV. 1
CIN0010102 TPS54232 2A, 28V, 1MHZ, DC-DC STEP DOWN 1
CIN0010106 MAXXAUDIO DSP MX5010B 1
CON0001079 CONNETTORE USB 67068-0000 1
CON0001128 26X1.27 VER. PICOFLEX SMD 90814-0026 (MOLEX) 1
CON0001129 SODIMM CONN. 144PIN SIDE ENTRY 54698-1440 (MOLEX) 1
CON0005001 CIRCULAR 5-PIN DIN GQ004005 3
CON0005011 PRESA MIDI MG/PR6L STE.(EC.5) 1

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
