Korg PA3X User Manual

= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST PLASTIC COMPONENTS
CODE DESCRIPTION REF. Q.TY
PLA0001046 CLIPS FERMACAVO PICCOLO UD1 LD1 MB MK OU 13
PLA0001047 CLIPS FERMACAVO GRANDE MB OU 4
PLA0001054 BUSTA IN CARTENE FOR.60X140 1
PLA0001057 COLLARE IN NYLON N16B RICHCO MB 1
PLA0001094 DISTAN.CST 6MM SRS4-04-01 MK 4
PLA0001143 DISTANZIALE 4.2 X 3.7 X 8 X 2.6 PA1XPRO DG 1
PLA0001144 LEDS LIGHT PLASTIC SHIELD SL DG 10
PLA0001146 MANOPOLA SLIDER PA1XPRO D 2
PLA0001157 TASTINO INTERUTTORE RETE PA1XPRO MK 1
PLA0010039 MANOPOLA SLIDER ( NOVODUR 700700) D 10
PLA0010084 TAPPO PER FORO PRESA VIDEO PA2X LD1 1
PLA0010149 POLICARBONATE FOR RIBBON CONTROL JG 1
PLA0010151 DISPLAY SMALL BUTTON NOVODUR 700700 DG 8
PLA0010152 DISPLAY BUTTON LIGHT GREY DG 4
PLA0010163 DIAL BUTTON SL 2
PLA0010165 NEW DIAL KNOB SL 1
PLA0010166 BUMPON RICHCO DE10-0074 WITH WASHER SHORE 70 LD2 5
PLA0010169 LEDS LIGHT PLASTIC SHIELD SL 1
PLA0010171 JOYSTICK TRANSPARENT FRAME JG 1
PLA0010172 BUTTON STEP 19 SL 5
PLA0010173 BUTTON STEP 19 WITH GLASS SL 23
PLA0010174 BUTTON STEP 17 WITH GLASS SL JG 6
PLA0010175 BUTTON STEP 17 SL 1
PLA0010178 RIBBON CONTROL PLASTIC SUPPORT JG 1
PLA0010184 USB FRAME LD1 1
PLA0010186 LEDS LIGHT PLASTIC SHIELD PITCH 8mm SL 2.5
PLA0010187 PA3X CONNECTOR COVER UD2 2
PLA0010188 FERMO PER CASSA UD2 2
PLA0010193 PASSACAVO EWSE-1-01 OU 1
PLA0010195 PROTEZIONE PER AGGANCIO CASSA UD2 1
PLA0010211 SLIDE KNOB UD2 1
PLA0010212 MANOPOLA POTENZIOMETRO PA3X D 3
PLA0010214 BUTTON STEP 19 GLASS ABS NOVODUR GREY 700700 SL 2
PLA0010215 BUTTON STEP 17 GLASS ABS NOVODUR GREY 700700 SL 56
PLA0010216 BUTTON STEP 17 ABS NOVODUR GREY 700700 SL 11
PLA0010217 ROUND BUTTON ABS NOVODUR GREY 700700 SL 4
PLA0010218 SLIDER 30MM BLACK FRAME SL 12
PLA0010220 BLACK DIAL BUTTONS SUPPORT SL 1
PLA0010223 PROTEZIONE PROFILO PA3X UD2 1
PLAL001024 KEYBOARD SIDE PANEL PA3X SILKSCREEN JG 1
PLAL001025 DISPLAY PLASTIC PANEL PAINTED DG 1

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
