Korg PA3X User Manual

= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST GRA1002132 IN/OUT BOARD
CODE DESCRIPTION REF. Q.TY
BOB0005002 FERRITE EMI BLM21B102SPT 16
CIN0003011 CIRC.INT. NMJ4556 AM SMD 1
CIN0010048 LOW NOISE LOW DIST MIC PREAMP INA217/SSM2019 1
CIN0010049 PSOC UC CYPRESS CY8C24123A-24SXI 1
CIN0010050 OPAMP 2CH NE5532D/NJM5532M SO8 9
CON0001078 CONN.BLK PICOFLEX 26 VIE 1.27 1
CON0010015 CONN. M. VER. PTH, 1 FILE, 4 VIE, 2,5MM, B4B-EH-A, JST 1
CON0010058 PRESA STEREO 6.3MM JACK NRJ6HH 6
CON0010059 COMBO CONNECTOR NEUTRIK NCJ10FI-H-0 1
CSTS002184 CST 2L KIP2184 SCHEDA PRESE PA3X 1
DIX0006003 DIODO SMD RLS-4148 2
DIX0006004 DIODO SMD SHOTTLY RB051L-40TE25 4
DIX0010005 SCHOTTKY DIODE BAV99WT1G 6
DIX0010006 ZENER DIODE, VZ=33V 500MW MMSZ5257BT1G 1
DIX0010007 ZENER DIODE, VZ=16V 500MW MMSZ5246BT1G 1
LED0010014 LED PTH 3MM AMBRA, L-7104ND KINGBRIGHT 1
POT0010001 POT.ROT.OR.270GRAD. 1KC X1,RK09KC1110001KC1N20AC 1
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 4
TRS0002002 TRANSISTOR PNP DTA114EKA SMD 5
TRS0002004 TRANSISTOR NPN 2SD2114KT146V 10
TRS0002008 REGOLATORE 78L05(SOT89) 100MA SMD 1
TRS0002010 J-FET N CHANEL J108 SOT23 (PMBFJ108) 4
TRS0002016 TRANSISTOR PNP SMD VCE=45, IC=0.5, BC807 1
TRS0010005 N CH. MOSFET 1.9A 30V FDN357N 2
TRS0010006 P CH. MOSFET -2A -30V FDN360P 2
TRS0010007 TR. NPN SMD 80V, 500MA, PMBTA06/MMBTA06 1
TRS0010008 TR. PNP SMD 80V, 500MA, PMBTA56/MMBTA56 1
PART LIST GRA0002183 61 KEYS KEYBOARD INTERFACE
CODE DESCRIPTION REF. Q.TY
BOB0005003 FERRITE MURATA DSS6NF31C223Q93A 16V 6A 1
BOB0005004 ARRAY IND.BLA31AG102SN4D SMD 11
CIN0002012 SMD 3TO8 LINE DEC.TC74HC138AFN 2
CIN0002056 IC.SW/LED/KBD SCANNER (NKS3,5)HD6433394A35F(S) 1
CIN0004005 RES.GEN.3,3V ETC811SUC 1
CIN0010009 OPAMP. R.TO R. 2CH LMC662CM SOP8 1
CON0001048 CON.MASCHIO 4 VIE P.2.54 1
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 2
CON0010001 CON. M. V. PTH, 2 F., 10 V., 1.27MM, 90325-0010 1
QUA0006004 QUARZO SMD HCM49 16MHZ 1
REY0006032 RETE ARRAY 10KE 0603X4 SMD 2
TRX0010000 TRIMMER ORIZ.P5MM 100K 1

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
