Distortion LG – 10 step
1-10 IN Left Direct To Left
2-10 IN Left Direct To Right
3-10 IN Left TG To Left
4-10 IN Left TG To Right
5-10 MIC To Left
6-10 MIC To Right
7-10 MIC To Out 1
8-10 MIC To Out 2
9-10 MIC To HP Left
10-10 MIC To HP Right
Connect 600ohm Audio Analyzer generator output to the label below specified inputs, then
check the relative output distorsion.
Mic gain potentiometer must be turned to the minimum level
MIC In Left In Right In Left Out Right Out Out 1 Out 2 HP L HPL R
1kHz 5Vpp Jack dummy < 0,1% Jack dummy
Jack dummy 1kHz 5Vpp Jack dummy < 0,1%
1kHz 5Vpp Jack dummy < 0,1% Jack dummy
Jack dummy 1kHz 5Vpp Jack dummy < 0,1%
1kHz 1Vpp < 0,1% Jack dummy
1kHz 1Vpp Jack dummy < 0,1%
1kHz 1Vpp < 0,1%
1kHz 1Vpp < 0,1%
0,5kHz 1Vpp < 0,1%
0,5kHz 1Vpp < 0,1%
Noise LG – 10 step
1-10 Left
2-10 Right
3-10 TG To Left
4-10 TG To Right
5-10 MIC To Left
6-10 MIC To Right
7-10 MIC To Out 1
8-10 MIC To Out 2
9-10 MIC To HP Left
10-10 MIC To HP Right
Connect Audio Analyzer input to the label below specified outputs, then check the relative
noises
Mic gain potentiometer must be turned to the minimum level
MIC In Left In Right In Left Out Right Out Out 1 Out 2 HP L HPL R
Jack dummy < -90dB Jack dummy
Jack dummy Jack dummy < -90dB
Jack dummy < 0,1% Jack dummy
Jack dummy Jack dummy < -90dB
< -90dB Jack dummy
Jack dummy < -90dB
< -90dB
< -90dB
< -90dB

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
