Korg PA3X User Manual

Audio In HG – 2 step
1-2 MIC To Left
2-2 MIC To Right
Connect 600ohm Audio Analyzer generator output to the label below specified inputs, then
check the relative output levels. (+/- 0,5Vpp)
Mic gain potentiometer must be turned to the maximum level
MIC In Left In Right In Left Out Right Out Out 1 Out 2 HP L HPL R
0,04Vpp 15Vpp Jack dummy
0,04 Vp Jack dummy 15Vpp
Distortion HG – 2 step
1-2 MIC To Left
2-2 MIC To Right
Connect 600ohm Audio Analyzer generator output to the label below specified inputs, then
check the relative output distorsion.
Mic gain potentiometer must be turned to the maximum level
MIC In Left In Right In Left Out Right Out Out 1 Out 2 HP L HPL R
0,04 Vpp < 0,1% Jack dummy
0,04 Vpp Jack dummy < 0,1%
Noise HG – 2 step
1-2 MIC To Left
2-2 MIC To Right
Connect Audio Analyzer input to the label below specified outputs, then check the relative
noises
Mic gain potentiometer must be turned to the maximum level
MIC In Left In Right In Left Out Right Out Out 1 Out 2 HP L HPL R
< -60dB
< -60dB

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
