Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST GRA0002167 LEFT PANEL BOARD
CODE DESCRIPTION REF. Q.TY
BAT0001001 BATTERIA 3V 220MA CR2032 1
CIN0010051 RTC STM M41T00SM6E/DS1340-33+ 1
CIN0010052 CIRC.INT. SN74AHCT138PW SMD 2
CIN0010053 PSOC UC CYPRESS CY8C24423A-24PVXI SSOP28 1
CIN0010090 TS3A44159 QUAD SPDT ANALOG SWITCH 1
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 1
CON0001087 CONN.MASCH.6 VIE PH20W6R ORIZ. 1
CON0010000 CONN. M. VER. PTH, 2 FILE, 8 VIE, 1.27MM 1
CON0010064 CONNETTORE ZOCCOLO BATTERIA CR2032 LT100-10 1
CON0010065 CONN. M. VER. PTH, 2 FILE, 6 VIE, 1.27MM MICS 06 1
CSTS002167 CST 2L SCHEDA PANNELLO SINISTRO PA3X 1
DIX0010004 ARRAY DIODI BAS16S/BAS16TW-MMBD4148TW 22
INT0010004 PULSANTINO SWITCH SMD ALPS SKHMQLE010 63
LED0010007 LED SMD 1206, AMBRA, KPTD-3216SECK KINGBRIGHT 58
LED0010009 LED SMD 1210 BIC. KPBD-3224SURKCGKC KINGBRIGHT 1
POT0001004 POT. LIN.10KB PAR.POL (RS30111FC010KBX1C/10WF) 12
QUA0006012 QUARZO SMD 32.768KHZ SMD PKG CM200S 1
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 5
TRS0002002 TRANSISTOR PNP DTA114EKA SMD 1
TRS0002013 TRANSISTOR PNP DTB113EK SMD 16
PART LIST GRA0002168 RIGHT PANEL BOARD
CODE DESCRIPTION REF. Q.TY
CIN0010052 CIRC.INT. SN74AHCT138PW SMD 2
CIN0010053 PSOC UC CYPRESS CY8C24423A-24PVXI SSOP28 1
CON0001076 CONN.BLK PICOFLEX 16 VIE 1.27 1
CON0001077 CONN.BLK PICOFLEX 20 VIE 1.27 1
DIX0010004 ARRAY DIODI BAS16S/BAS16TW-MMBD4148TW 16
INT0010004 PULSANTINO SWITCH SMD ALPS SKHMQLE010 45
INT0010006 ENCODER INCREMENTALE ALPS EC12E24204A7 1
LED0010007 LED SMD 1206, AMBRA, KPTD-3216SECK KINGBRIGHT 32
LED0010009 LED SMD 1210 BIC. KPBD-3224SURKCGKC KINGBRIGHT 2
POT0001006 POT.ROT.LIN.10KB VERT. RK09K1130 20MM FLAT COLLAR 3
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 3
TRS0002013 TRANSISTOR PNP DTB113EK SMD 12
PART LIST GRA0002170 DISPLAY FRAME BOARD
CODE DESCRIPTION REF. Q.TY
CON0010141 CONN. F. OR. SMD 10 VIE 1MM 10FMS-10SP-TF 1
DIX0010004 ARRAY DIODI BAS16S/BAS16TW-MMBD4148TW 4
INT0010004 PULSANTINO SWITCH SMD ALPS SKHMQLE010 12
LED0010007 LED SMD 1206, AMBRA, KPTD-3216SECK KINGBRIGHT 4

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
