Korg PA3X User Manual

= ONLY FOR U.S.A. VERSION
= ONLY FOR U.K. VERSION
= ONLY FOR AUSTRALIAN VERSION
= ONLY FOR JAPANESE VERSION
Pa3X 61keys PART LIST
D = Disassembly UD1 = Upper case Disassembly 1 UD2 = Upper case Disassembly 2
SL = Switches Layout LD1 = Lower case Disassembly 1 LD2 = Lower case Disassembly 2 DG = Display Group
JG = Joystick Group MB = Main Board group OU = Option Unit MK = Main Filter and Keyboard Group
PART LIST GRA0002165 MAIN BOARD (continue)
CODE DESCRIPTION REF. Q.TY
CON0005013 BLACK RCA PLUG GP305520 1
CON0010009 PRESA USB TYPE A 1
CON0010014 CONN. M. OR. PTH, 1 FILE, 3 VIE, 2,5MM, S3BEH, JST 1
CON0010018 CONN. MASCHIO OR. PTH, 1 FILE, 5 VIE, 2,5MM, S5BEH, JST 1
CON0010020 CONN. M. VER. PTH, 1 FILE, 4 VIE, 3,96MM, B4P-VH-K, JST 1
CON0010035 CONN. M. VER. PTH, 1 FILE, 7 VIE, 2,5MM, B7B-EH-A, JST 1
CON0010058 PRESA STEREO 6.3MM JACK NRJ6HH 2
CON0010062 CONN. M. VER. SMD 2 FILE 10 VIE 1.27MM MICS/SMD 10 1
CON0010135 CONN. M. VER. SMD 2 FILE 12 VIE 1.27MM MICS/SMD 12 LU. 1
CON0010136 CONN. M. VER. SMD 2 FILE 20 VIE 1.27MM MICS/SMD 12 LU. 1
CON0010140 CONN. SMD JST 50 VIE 0.5 MM ZIF 1
DIX0006000 DIODO DOPPIO SMD DA204KT146 7
DIX0006003 DIODO SMD RLS-4148 7
DIX0010008 SCHOTTKY DIODE SK54 5A 40V 2
DIX0010009 ZENER DIODE, VZ=8V2 500MW MMSZ5237BT1G 1
DIX0010010 DIODO ULTRA FAST 2A, 140V ER2D 2
DIX0010015 SCHOTTKY DIODE SK24 2A 40V 1
GRA0002188 DC/DC CONV BOARD +15VIN TO -15VOUT 0,5A 1
INT0010007 INTER. VER. 2 POS. 125V 0.3° 1
QUA0006004 QUARZO SMD HCM49 16MHZ 1
QUA0006005 QUARZO SMD HCM49 24.576MHZ 1
QUA0006012 QUARZO SMD 32.768KHZ SMD PKG CM200S 1
QUA0010000 QUARZO SMD HCM49 12MHZ 1
REY0006002 RETE ARRAY 22E 0603X4 SMD 38
REY0006010 RETE ARRAY 100E 0603X4 SMD 10
REY0006022 RETE ARRAY 1KE 0603X4 SMD 8
REY0006032 RETE ARRAY 10KE 0603X4 SMD 12
REY0006133 RETE ARRAY 3K3 0603X8 RAC168 6
REY0010000 RETE RESISTIVA SMD 0603 33 OHM X 4 5% 40
REY0010001 RETE RESISTIVA SMD 0603 47 OHM X 4 5% 37
REY0010002 RETE RESISTIVA SMD 0603 56 OHM X 4 5% 20
REY0010003 RETE RESISTIVA SMD 0603 68 OHM X 4 5% 5
TRA0001013 TRANSF. S/PIDIF DIGITAL AUDIO PE-65612 2
TRS0002001 TRANSISTOR NPN DTC114EKA SMD 4
TRS0002002 TRANSISTOR PNP DTA114EKA SMD 2
TRS0002004 TRANSISTOR NPN 2SD2114KT146V 1
TRS0002006 REGOL.+5V 0.5A BA178M05FP 1
TRS0002013 TRANSISTOR PNP DTB113EK SMD 4
TRS0010000 REGOLATORE LINEARE, -12V, 0,5°, NJM79M12DL1A, TO252 1
TRS0010001 REGOLATORE LINEARE, 12V, 0.5°, 78M12, TO252 1
TRS0010011 REG. LIN. SMD 2A ADJ LOW DROP, BA00DD0WHFP 1
TRS0010020 P CH. MOSFET -3A -30V IRLML5203PBF 1

Korg PA3X Specifications

General

Type	Arranger Keyboard
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61 keys (with velocity and aftertouch)
Display	7-inch TouchView TFT display
Storage	Internal SSD
Weight	17.5 kg
Styles	Over 400 styles
User Styles	Up to 1, 200
Sounds	Over 1, 100
Sampling	Yes, with Time Slice function
Sequencer	16-track sequencer
Outputs	L/R
Inputs	Mic/Line, Guitar
USB	Yes, 2 ports
Audio Recording	MP3 recording and playback
