3–1: Key Zone
64
With a setting of
12
, the volume will gradually increase until the key one octave above the Bottom
Key will sound at the original volume.
With a setting of
60
, the volume will gradually increase until the key five octaves above the Bot-
tom Key will sound at the original volume.
3–1d: Bottom Key [C–1…G9]
Specifies the bottom key of the range in which timbres 1–8 will sound.
The key setting can also be input from the keyboard.
▼
Page Menu Command
3–1A: Write Combination
This command writes an edited combination into the specified combination number. Be sure to
write important combinations. If you turn the power off or select another combination before writ-
ing, it will not be possible to recover the edited data.
For details refer to Basic Guide page 23, “9. Writing a program or combination”.
Bottom
Slope
Bottom Key
Top
Slope
Top Key
Key
Volume
Volume change as affected by keyboard position
