1 Information on This Document
1.5 How to use this document
8
EasyCut B 970
Original Operating Instructions 150000711_01_en
Icon Explanation Icon Explanation
1
Reference sign for part
I
Position of a part (e.g. move from
position I to position II)
X
Dimensions (e. g. also W = width,
H = height, L = length)
Magnification of display detail
LH
Left side of machine
RH
Right side of machine
Direction of travel Direction of motion
Reference line for visible material Reference line for covered mater-
ial
Centre line Cable routes
Nm
Tighten screws according to the
tightening torque table
XXX Nm
Tighten screws to the specified
tightening torque
Open Closed
Apply liquid lubricant (e.g. lubricat-
ing oil)
Apply lubricating grease
Warning signs
Warnings of dangers are separated from the remaining text as warning signs and are identified
with a danger sign and signal words.
The warning signs must be read and the measures must be observed in order to prevent
personal injury.
Explanation of danger sign
This is the danger sign that warns of a risk of injury.
Please observe all notes marked with the danger sign in order to avoid injuries or death.
Explanation of signal words
DANGER
The signal word DANGER warns of a hazardous situation which will result in serious injuries
or death if the warning sign is ignored.
WARNING
The signal word WARNING warns of a hazardous situation which will result in serious injuries
or death if the warning sign is ignored.
CAUTION
The signal word CAUTION warns of a hazardous situation which will result in minor to
moderate injuries if the warning sign is ignored.
Example of a warning sign:
