6 Control unit Basis (Electric twine starter)
• When doing any assembly work on the round baler, always disconnect the voltage feed to
the control unit.
• Repair work on the hydraulic system should be carried out by trained specialists only!
• When assembling the control unit make certain that the connecting cables to the round
baler do not tense during turning or come into contact with the tractor wheels.
Control unit Basis
6.1 General Information
1. wrapping start button
2. ON/OFF switch
3. control line to baler
4. power supply
Special Safety Instructions
When doing welding work on the round baler or tractor with attached round baler,
overvoltage could cause damage to the electric components of these control unit. For
this reason, detach the control unit from the tractor and disconnect the cable
connections.
