Krone Round Pack 1250 - Sensor for the Cutting System Blades (Special Equipment

IX - 8
Maintenance
9.2.7 Sensor for the Cutting System Blades
(Special Equipment)
Comfort
The sensor (1) for the cutting system blades is located on
the right side of the machine on the blade shaft.
Adjustment:
• Undo lock nuts (2).
• Adjust sensor so that gap a between the sensor and
the lever (3) is a = 1 - 2 mm when the lever is in the
raised position.
• Tighten the nuts together.
The height of the sensor is also adjustable. Adjust the
sensor so that the lamp inside the control box flashes
when the lever is turned approximately 10°.
2
1
a
3
RB-4-004
