CONTROLS 19
4.32Foot brake pedal
600023-10
Foot brake pedal is located in front of the right footrest.
The rear brake is engaged with the foot brake pedal.
4.33Side stand
600011-10
Note
Danger of damage The parked vehicle can roll away or fall over.
– Always place the vehicle on a firm and even surface.
Note
Material damage Damage and destruction of components by excessive load.
– The side stand is designed for the weight of the motorcycle only. Do not sit on the
motorcycle when it is supported by the side stand only. The side stand and/or the
frame could be damaged and the motorcycle could fall over.
To park the motorcycle, remove the rubber band , fold down the side stand with
your foot and rest the motorcycle against it.
600012-10
When you are riding, the side stand must be folded up and secured with the rubber
band .
4.34Steering lock
600103-10
The steering lock is fitted on the left of the steering head.
The steering lock is used to lock the steering. Steering, and therefore riding, is no
longer possible.
4.35Locking the steering
Note
Danger of damage The parked vehicle can roll away or fall over.
– Always place the vehicle on a firm and even surface.
– Park the motorcycle.
– Turn the handlebar as far as possible to the right.
