TECHNICAL DATA - CHASSIS 81

15.2Tires

Front tire Rear tire

90/90 - 21 54S TT

Michelin T63

130/80 - 18 66S TT

Michelin T63

Additional information is available in the Service section under:

http://www.ktm.com

15.3Capacity - fuel

Fuel tank capacity

Fuel tank half, front left,

approx.

9.0 l (2.38 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 97)

Fuel tank half, front right,

approx.

9.0 l (2.38 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 97)

Rear fuel tank, approx. 18.0 l (4.76 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 97)

Total fuel capacity, approx. 36.0 l (9.51 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 97)
