21 TECHNICAL DATA
116
Handle bar end screw M8 15 Nm (11.1 lbf ft)
Nut, manifold on cylinder head M8 Tighten the nuts evenly. The plate
should not be bent.
Copper paste
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, connection lever on frame M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, foot brake lever M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front footrest bracket M8 25 Nm (18.4 lbf ft)
Screw, fuel tank bracket M8 15 Nm (11.1 lbf ft)
Screw, fuel tank, bottom M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fuel tank, top M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, grab handle M8 10 Nm (7.4 lbf ft)
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, heel protector M8x12 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, main silencer holder M8 25 Nm (18.4 lbf ft)
Screw, main silencer holder on
fuel tank
M8 25 Nm (18.4 lbf ft)
Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft)
Screw, side stand bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, spring holder plate on side
stand bracket
M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft)
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Engine carrying screw M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft)
Screw, handlebar support M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
