TECHNICAL DATA 21
117
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft)
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft)
Copper paste
Screw, swingarm pivot M12x1.5 80 Nm (59 lbf ft)
Nut, angle lever to link fork M14x1.5 100 Nm (73.8 lbf ft)
Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft)
Screw, radiator temperature sensor M18 20 Nm (14.8 lbf ft)
Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft)
Loctite
®
243™
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft)
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft)
