Kubota LA340 - Foot Controls and Hand Controls; Performing the Test Operation of the Loader; Removing Air from the Hydraulic System

Implement Remarks BX23S
Box blade
Max. cutting width
152 cm
(60 in.)
Max. weight
170 kg
(375 lbs.)
Snow blower (Front)
Max. working width
127 cm
(50 in.)
Max. weight
160 kg
(353 lbs.)
Sub frame Necessary
Post hole digger Digging depth
114 cm
(45 in.)
Rotary broom Cleaning width
119 cm
(47 in.)
Trailer
Max. load capacity
800 kg
*4
(1765 lbs.)
Max. weight
1100 kg
(2425 lbs.)
NOTE :
• Implement size may vary depending on soil operating conditions.
*1 KUBOTA provides BT603 backhoe for BX23S.
No other backhoe installed by 3-point hitch is permitted for BX23S.
*2 KUBOTA provides LA340 and LA340S Front-end Loader for BX23S.
*3 The value contains the weight of KUBOTA standard bucket.
*4 Reduce speed and trailer loads when operating in slippery conditions or when operating on slopes and using front wheel drive.
IMPLEMENT LIMITATIONS
BX23S, LA340, BT603
43
