KUHN Venta 3030 - Seeding Disk Cleaners; Radar

10. - Optional equipment
Venta 3030-3530-4030
101
RN034AGB D
Seed Drill
10.8 Seeding disk cleaners
The set consists of a scraper for two disks.
10.9 Radar
Transport position
The seed disk scrapers stop the accumulation of soil
at the level of the seed disk.
The radar can determine the movement speed.
- Remove R-clip.
- Raise the radar arm.
- Hold the radar arm with one hand.
- Remove the pin from position (1).
- Secure pin (2) using R-clip.
2
1
