7. - Putting into service
Venta 3030-3530-4030
53
RN034AGB D
Seed Drill
7.4.2 Description of coupling elements
The machine is equipped with:
• A 7-pin electric plug for the electrical signalling
equipment.
• An electric 9-pin plug to supply the ISOBUS
module
or
• An electric 3-pin plug to supply the
QUANTRON S-2 module
• Hydraulic hoses for the blower drive (depending
upon specification).
• 2 hydraulic hoses for the third hydraulic point
(depending upon specification)
• One hydraulic hose for the pre-emergence
markers (depending upon specification).
• Two 3 pin plugs for the markers (depending upon
specification).
• A 5 pin plug for the hydraulic valve (depending
upon specification).
• A 3 pin plug for the work position sensor
7.4.3 Blower unit drive
The VENTA 1030 seed drill is factory fitted with a
hydraulic blower drive.
2300 min
-1
4300 min4200
-1
max
