KUHN Venta 3030 - Adjustments in Working Position

9. - Instructions for work
Venta 3030-3530-4030
71
RN034AGB D
Seed Drill
9.3 Adjustments in working position
Before:
- Position the power harrow horizontally with
respect to the ground.
- Adjust the impulse wheel depth.
or

Hydraulic top link
- Completely remove the third hydraulic point from
the machine.
- Position the hopper using the hydraulic top link set
in the most horizontal position with regards to the
ground.
- Loosen counter nut (1).
- Turn rod (2) until the hopper is horizontal with
regards to the ground.
- Tighten checknut (1).
2
1
 Mechanical top link
- Loosen nut (1).
- Rotate the mechanical top link and adjust length so
that the hopper is horizontal with regards to the
ground.
- Tighten nut (1).
1
