Venta 3030-3530-4030
94
10. - Optional equipment
RN034AGB D
Seed Drill
10. Optional equipment
10.1 Tramline shut-off valves
10.1.1 Removal of the mechanical valve
Further information is given in the operators'
manual supplied with the kit.
Remove the distribution head cover:
- Loosen the 3 wing nuts (1).
- Remove the 3 washers (2).
- Remove cap.
1
2
- Open collar (1).
- Disconnect the seed transfer tube.
- Loosen and remove screws (2).
• Eliminate the screws.
- Remove the 4 wedges (3) and eliminate them.
1
2
3
3
