7. - Putting into service
Venta 3030-3530-4030
45
RN034AGB D
Seed Drill
7.2 Control box description
 Description of the connection
The functioning and setting of the control boxes
are indicated in the complementary instructions
supplied.
The control terminal must be easily accessible from
the tractor cab.

Control terminal mounting
(Optional equipment)
Fit holder to the rear of the control terminal

Control terminal removal
Store the control terminal in a dry place free of dust.
Never connect a battery charger or perform
welding tasks without having previously
disconnected the terminal power.
The control terminal is connected to:
• 1 ISOBUS connector (ISO 11783)
