Venta 3030-3530-4030

7. - Putting into service

RN034AGB D

Seed Drill

- QUANTRON S-2

• Push-button on the hopper frame for lighting

inside the hopper and of the metering unit.

• Pushbutton on the seedbox for the starting or

stopping of the flow test.
