KUHN Venta 3030 - Lower the Pre-Emergence Marker (Optional Equipment)

Venta 3030-3530-4030
70
9. - Instructions for work
RN034AGB D
Seed Drill
9.2.3 Lower the pre-emergence marker
(Optional equipment)
- Lift the pre-emergence marker arm by hand.
- Remove lock pin and pin from position (1).
- Raise the lever (2) to unlock the arm.
- Lower the pre-emergence marker.
- Refit pin (3) to the required position.
- Insert and secure pin with lynch pin.
1
3
2
