Venta 3030-3530-4030

5. - Machine specifications

RN034AGB D

Seed Drill

5.3.4 Hydraulic blower drive

Hydraulic blower drive is from by the tractor

hydraulic circuit and independent of the soil

preparation tool.

 Blower (Constant current)

 Blower (VARIO)
