KUHN Venta 3030 - Adjustment of the Fill Level Sensor

7. - Putting into service
Venta 3030-3530-4030
61
RN034AGB D
Seed Drill
7.5.3 Adjustment of the fill level sensor
- In the event of a gap between the upper wheels of
the tractor, shift the tramline valves backwards.
• Tractor wheel track: L >1.80 m (5’11’’).
- If there are larger tractor tires, fit different tramline
valves.
• A maximum of 4 tramline valves are possible per
tire.
The lower fill level sensor can be fitted in 3 different
positions.
• Left side of the seed box: lower fill indicator for
normal seed.
- Determin adapted position (1) or (2)of the low level
indicator
• At the back of the seed box: lower fill indicator for
fine seed (3)
3
1
2
