9. - Instructions for work
Venta 3030-3530-4030
75
RN034AGB D
Seed Drill
Ground pressure
Too aggressive a tine position increases tine
wear and results in more frequent
replacement.
Adjust so as to have the tine tips working.
The ground pressure is adjusted using the spring (1)
position.
- Reduce the number of coils to the rear of R-clip (2)
to reduce the ground pressure exerted by the
following harrow.
- Increase the number of coils to the rear of the pin
to increase the ground pressure exerted by the
following harrow.
