9. - Instructions for work
Venta 3030-3530-4030
91
RN034AGB D
Seed Drill
- Remove pin (2).
- Leave the locking (1) in position.
1
2
- Insert the axle (1) again into the bore at the front of
the roller to lock the rotary harrow and the roller.
- Proceed the same way on the other side.
1
- Remove locking pin (1).
1
