Kyocera ECOSYS FS-C8650DN User Manual

Part Names
1-2
Exterior / Cassettes
1 Front Cover
2 Main Tray
3 Paper stopper
4 Job Separator
5 Operation Panel
6 USB Memory Slot (A1)
7 Right Cover 1 Lever
8 Right Cover 1
9 Paper Length Guide
10 Paper Width Adjusting Tab
11 (Paper Width Guide) Lock
12 Cassette 1
13 Cassette 2
14 Right Cover 2 Lever
15 Right Cover 2
16 Paper Width Guide
17 Main Power Switch
18 Multi Purpose Tray
19 Support Tray Section of the Multi Purpose Tray
20 Right Cover 3 Lever
21 Right Cover 3
22 Handles
9
812 7
10
4
11
56
3
14
15
16
17
18
19
20
21
22
12
13
