Kyocera ECOSYS FS-C8650DN - Duplex Unit

8-29
Troubleshooting
Duplex unit
Follow the steps below to clear paper jams in the duplex unit.
1 Pull up right cover 1 lever and open the right cover 1.
2 Remove the jammed paper.
3 Open the Conveyor Guide (A3) and remove the jammed paper.
A3
