Kyocera ECOSYS FS-C8650DN - When Options Are Installed

Part Names
1-4
When options are installed
1 Mailbox
2 Document Finisher
3 Cassette 3 to 7
• 3-a: Cassette 3 • 3-b: Cassette 4 • 3-c: Cassette 5
• 3-d: Cassette 6 • 3-e: Cassette 7 • 3-f: Cassette 5
• 3-g: Cassette 3 or 6 • 3-h: Cassette 4 or 7
1
2
3-h 3-g
3
3-f
3-c
3-d
3-e
3-a
3-b
