Kyocera ECOSYS M4125idn User Manual

3-35
Preparation before Use > Adding a Destination
3
Add the address.
E-mail Address
[E-mail Address] > Enter the E-mail address. > [OK]
The Folder (SMB) Address
[SMB] > [Host Name], [Path], [Port], [Login User Name] or [Login Password] > [OK]
The table below explains the items to be entered.
To search for a folder on a PC on the network and add it, perform the operation below.
[Menu] > [Search Folder from Network] or [Search Folder by Host Name]
If you selected "Search Folder from Network", you can enter the "Domain/Workgroup", and "Host Name" to
search PCs on the network for the destination.
If you pressed "Search Folder by Host Name"[Next], you can search all PCs on the network for a destination.
A maximum of 500 addresses can be displayed. To display the login user name and login password entry screen,
perform the operation below.
On the screen that appears, select the host name (computer name) and then select [Next >].
NOTE
You can enter up to 128 characters.
For details on entering characters, refer to the the following:
Character Entry Method (12-11)
NOTE
For the computer name, share name, domain name, and user name, enter the information that you noted when
you created the shared folder.
For details on creating shared folders, refer to the following:
Preparation for Sending a Document to a Shared Folder in a PC (3-24)
Item Description Max. No. of
Characters
Host Name Computer name 64 characters
Path Share name
For example: scannerdata
If saving in a folder in the shared folder:
share name
\folder name in shared folder
128 characters
Port Port number (Normally 445) 1-65535
Login User Name If the computer name and domain name are the same:
User Name:
For example: james.smith
If the computer name and domain name are different:
Domain name
\User name
For example: abcdnet\james.smith
64 characters
Login Password Windows logon password
(Case sensitive.)
64 characters

Kyocera ECOSYS M4125idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Print technology	Laser
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.8 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	25 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (black)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	33.6 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	15000 pages per month
Recommended duty cycle	4000 - 8000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	49 dB
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	65 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	410 W
Energy Star Typical Electricity Consumption (TEC)	0.96 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	72000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
