Kyocera ECOSYS M4125idn User Manual

3-36
Preparation before Use > Adding a Destination
The Folder (FTP) Address
[SMB] > [Host Name], [Path], [Port], [Login User Name] or [Login Password] > [OK]
The table below explains the items to be entered.
*1 When the FTP server is based on Linux/UNIX, the path including the sub-folder is combined by the slash (/) and not the
back-slash(
\).
1 If you want to specify an address number, select [Address Number].
2 Use [+] / [-] or the numeric keys to enter an address number (001 to 250).
To have the number assigned automatically, specify 000.
3 Select [OK].
4
Check if the destination entry is correct > [Save]
The destination is added to the Address Book.
NOTE
• For details on entering characters, refer to the the following:
Character Entry Method (12-11)
• Search and send are not supported when two-byte characters are used in the host name, domain name,
workgroup name, or user name.
• To check the connection to the specified computer, select [Menu] > [Connection Test]. If the connection fails,
check the entries you made.
Item Description Max. No. of
Characters
Host Name Host name or IP address of FTP server 64 characters
Path
*1
Path for the file to be stored
For example:
\Use\ScanData
If no path is entered, the file is stored in the home directory.
128 characters
Path Port number (Normally 21) 1-65535
Login User Name FTP server login user name 64 characters
Login Password FTP server login password 64 characters
NOTE
• For details on entering characters, refer to the the following:
Character Entry Method (12-11)
• To check the connection to the specified FTP server, select [Menu] > [Connection Test]. If the connection fails,
check the entries you made.
NOTE
• An address number is ID number for a single destination. You can select any available number for groups.
• If you specify an address number that is already in use, an error message will appear and the address will not
be added.

Kyocera ECOSYS M4125idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Print technology	Laser
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.8 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	25 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (black)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	33.6 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	15000 pages per month
Recommended duty cycle	4000 - 8000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	49 dB
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	65 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	410 W
Energy Star Typical Electricity Consumption (TEC)	0.96 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	72000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
