Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
4-70
9. Detach the right rear cover (a) while
twisting it.
10. Remove the screw(M3×10TP)(b).
11. Release the protrusion (e) by using a
flat-blade screwdriver (d).
12. Detach the Wi-Fi cover(c).
Figure 4-126
13. Remove two screws(M3×10TP)(a).
14. Release two hooks (b) of the upper rear
cover (c) and detach it.
Figure 4-127
a
b
c
1
2
3
d
e
b
a
b
c
