Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
4-71
15. Release four hooks (b) at the front side
of the left cover (a).
Figure 4-128
16. Release two hooks (b) at the rear side
of the left cover (a).
17. While tilting the left cover (a), detach it
in the direction of the arrow.
Figure 4-129
b
b
a
b
a
