Kyocera FS-C5350DN

2K8
1-5-30
4. Remove the connector A.
5. Remove the developing fan motor 1.
6. Remove the two connectors B.
7. Remove the FFC.
Figure 1-5-41
8. Remove the three FFCs.
9. Remove the two connectors.
Figure 1-5-42
Developing fan motor 1
Connector B
Connector B
Connector A
FFC
FFC
FFC
Connector
FFC
Connector
