Kyocera FS-C5350DN Service Manual

2K8
2-3-6
YC23 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the toner
motor Y
2 TNMYDRN O 0/24 V DC Toner motor Y: On/Off
YC24 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the toner
motor C
2 TNMCDRN O 0/24 V DC Toner motor C: On/Off
YC25 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the toner
motor M
2 TNMMDRN O 0/24 V DC Toner motor M: On/Off
YC26 1 DLPCLDRN O 0/24 V DC Developing clutch K: On/Off
Connected
to the devel-
oping clutch
K, develop-
ing motor K,
Registration
clutch and
paper feed
clutch
2 +24V3 O 24 V DC 24 V DC power source
3 MOTKREV O 0/3.3 V DC Developing motor K drive switch signal
4
DLPMOTKRDYN I 0/3.3 V DC Developing motor K ready signal
5 SPEEDSEL O 0/3.3 V DC Developing motor K speed selection signal
6 DLPMOTKCLK O 0/3.3 V DC (pulse) Developing motor K clock signal
7 DLPMOTKREN O 0/3.3 V DC Developing motor K: On/Off
8 GND - - Ground
9 +24V3 O 24 V DC 24 V DC power source
10 REGCLDRN O 0/24 V DC Registration clutch: On/Off
11 +24V3 O 24 V DC 24 V DC power source
12 FEDCLDRN O 0/24 V DC Paper feed clutch: On/Off
13 +24V3 O 24 V DC 24 V DC power source
YC27 1 MOTREV O 0/3.3 V DC Developing motor MCY drive switch signal
Connected
to the devel-
oping motor
MCY
2 DLPMOTRDYN I 0/3.3 V DC Developing motor MCY ready signal
3 SPEEDSEL O 0/3.3 V DC Developing motor MCY speed switch signal
4 DLPMOTCLK O 0/3.3 V DC (pulse) Developing motor MCY clock signal
5 DLPMOTREN O 0/3.3 V DC Developing motor MCY: On/Off
6 GND - - Ground
7 +24V3 O 24 V DC 24 V DC power source
YC28 1 LMOTDRN O 0/24 V DC Lift motor: On/Off
Connected
to the lift
motor
2 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
