Kyocera FS-C5350DN Service Manual

2K8
2-3-13
YC8 1 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
Connected
to the drum
PWB C
2 ERASEDR O 0/24 V DC Eraser lamp C: On/Off
3 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
4 GND - - Ground
5 +3.3V1 O 3.3 V DC 3.3 V DC power source
6 N.C. - - Not used
7 DA1 O 0/3.3 V DC Data address signal
8 DA0 O 0/3.3 V DC Data address signal
YC9 1 GND - - Ground
Connected
to the drum
PWB C
2 ERASECDR O 0/24 V DC Eraser lamp C: On/Off
3 N.C. - - Not used
YC10 1 GND - - Ground
Connected
to the devel-
oping PWB
C
2 TNSENC I Analog Toner sensor C detection voltage
3 +3.3V2 O 3.3 V DC 3.3 V DC power source
4 N.C. - - Not used
YC11 1 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
Connected
to the drum
PWB M
2 ERASEDR O 0/24 V DC Eraser lamp M: On/Off
3 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
4 GND - - Ground
5 +3.3V1 O 3.3 V DC 3.3 V DC power source
6 N.C. - - Not used
7 DA1 O 0/3.3 V DC Data address signal
8 DA0 O 0/3.3 V DC Data address signal
YC12 1 GND - - Ground
Connected
to the drum
PWB M
2 ERASMCDR O 0/24 V DC Eraser lamp M: On/Off
3 N.C. - - Not used
YC13 1 GND - - Ground
Connected
to the devel-
oping PWB
M
2 TNSENM I Analog Toner sensor M detection voltage
3 +3.3V2 O 3.3 V DC 3.3 V DC power source
4 N.C. - - Not used
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
