Kyocera FS-C5350DN Service Manual

2K8
1-4-29
(6)Main charging is
not performed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
(See page 1-5-34).
High voltage PWB - Engine PWB (YC16)
Defective main charger unit Replace the main charger unit (See page 1-5-15).
Defective high voltage
PWB.
Replace the high voltage PWB (See page 1-5-34).
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(7)No developing
bias is output.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
(See page 1-5-34).
High voltage PWB - Engine PWB (YC16)
Defective high voltage
PWB.
Replace the high voltage PWB (See page 1-5-34).
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(8)Transfer charging
is not performed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
(See page 1-5-34).
High voltage PWB - Engine PWB (YC16)
Defective high voltage
PWB.
Replace the high voltage PWB (See page 1-5-34).
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(9)The message
requesting paper to
be loaded is shown
when paper is
present in the cas-
sette.
Defective paper sensor 1/2. Replace the engine PWB (See page 1-5-29).
Broken paper sensor 1/2
actuator.
Check the bending of the actuator lever of the paper sensor 1/2 if
there is trouble, remedy or replace.
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(10)The message
requesting paper to
be loaded is shown
when paper is
present in the MP
tray.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
MP tray sensor - Engine PWB (YC21)
Defective MP tray sensor. Replace the MP tray sensor.
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(11)The size of paper
in the cassette is not
displayed correctly.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Cassette size switch - Engine PWB (YC9)
Defective cassette size
switch.
Replace the cassette size switch.
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
(12)A paper jam in
the paper feed sec-
tion, paper conveying
section, fuser sec-
tion or duplex section
is indicated when the
power switch is
turned on.
A piece of paper torn from
copy paper is caught
around registration switch,
duplex conveying sensor or
paper exit sensor.
Check and remove if any.
Defective registration sen-
sor or duplex conveying
sensor.
Replace the registration sensor or duplex conveying sensor.
Defective paper exit sensor. Replace the paper exit PWB.
Defective engine PWB. Replace the engine PWB (See page 1-5-29).
Problem Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
