2K8
1-5-13
5. Check or replace the developing unit and
refit all the removed parts.
NOTE:
Remove the cap before installing the new
developing unit.
When reinstalling the developing unit, press
it down until the lever of developing unit is
engaged with the notch.
If it is difficult to engage the lever, press the
unit down while rotating the gear to engage
it.
Figure 1-5-15
Lever
Lever
Gear
Notch
Developing unit
New developing unit
Cap
Notch
To Next Page
