Kyocera KM-2550

2FT
1-6-4
5. Remove the separation pulley unit from the
lower paper feed unit.
6. Remove the separation pulley from the sep-
aration pulley unit.
7. Replace the separation pulley and refit all
the removed parts.
Figure 1-6-4
Separation pulley
Lower paper feed unit
Separation pulley unit
