Kyocera KM-2550

2FT-3.0
2-4-8
Maintenance parts list
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY, PAPER FEED 2AR07220 7 39
Separation pulley PULLEY, SEPARATION 2AR07230 7 40
Forwarding pulley PULLEY, LEADING FEED 2AR07240 7 41
Drawer paper feed pulley PULLEY, PAPER FEED 2AR07220 4 16
Drawer separation pulley PULLEY, SEPARATION 2AR07230 4 17
Drawer forwarding pulley PULLEY, LEADING FEED 2AR07240 4 18
Bypass paper feed pulley PARTS, BYPASS PULLEY, SP 2C993130 8 19
Bypass separation pad PARTS, BYPASS PAD, SP 2C993140 8 15
Left registration roller ROLLER REGIST LEFT 2C916020 6 1
Right registration roller RIGHT ROLL REGIST 2C907180 7 9
Registration cleaner PARTS, REGIST CLEANER, ASSY 2C993210 7 27
Feed roller ROLLER FEED 3HW06020 4 3
Feed pulley PULLEY FEED 2BL16080 3 24
Slit glass CONTACT GLASS ADF 2C912280 10 27
Contact glass CONTACT GLASS 2C912250 10 24
Mirror 1 MIRROR A 2C912390 10 37
Mirror 2 and mirror 3 MIRROR B 2AV12160 10 4
Lens LENS 2C912500 - -
Reflector REFLECTOR SCANNER 2C912110 10 12
Exposure lamp LAMP SCANNER YG 2FT12010 10 10
Front scanner rail FRONT RAIL SCANNER 2C912070 - -
Rear scanner rail REAR RAIL SCANNER 2C912080 - -
Original size detection sensor SENSOR ORIGINAL 2C912090 10 55
Laser scanner unit PARTS, LK-420, SP 302FT93070 2FT93070 14 1
Transfer roller ROLLER TRANSFER 2FT17010 6 37
Separation electrode PLATE STA ELIMINATION 2FT17030 6 28
Developing unit PARTS, DV-420, SP 302FT93050 2FT93050 11 1
Drum unit PARTS, DK-420, SP 302FT93041 2FT93041 11 5
Fixing unit PARTS, FK-420(A), SP 302FT93021 2FT93021 12 1
Fixing unit PARTS, FK-420(E), SP 302FT93031 2FT93031 12 1
Heat roller ROLLER HEAT 302FT20011 2FT20011 12 26
Press roller ROLLER PRESS 2C920060 12 6
Heat roller separation claw SEPARATOR ASSY B 302FT20160 2FT20160 12 24
Exit roller ROLLER EXIT INNER 2C921010 9 17
Exit pulley PULLEY EJECT 2C921360 9 46
Switchback roller ROLLER FEED SHIFT 2C921020 9 18
Switchback pulley PULLEY FEED SHIFT 2C921040 9 19
