Kyocera KM-2550

2FT
1-6-12
6. Push the fitting portions of the bypass upper
cover. Remove the bypass upper cover from
the bypass unit.
Figure 1-6-19
7. Detach the connector and remove the
bypass lower cover from the MFP.
Figure 1-6-20
8. Remove the paper conveying unit from the
MFP.
Figure 1-6-21
Bypass upper cover
Bypass lower cover
Connector
Paper conveying unit
