2WA/2NJ/2RK
3-112
Adjustment 1
Change the width of B.
Adjuster plate relocation method
1. Push the folding unit release lever and
pull out the folding unit.
Figure 3-105
2. Open the upper folding unit cover (a)
upward and remove two screws (b) to
remove the eject cover (c).
Figure 3-106
a
b
a
b
c
b
c
To Next Page
