2WA/2NJ/2RK
4-100
13. Remove the ISU front cover (b) in the
direction of the arrow.
Figure 4-147
14. Remove one screw (a) (M3x8) and then
remove the rear operation unit cover B
(b) by sliding in the direction of the
arrow.
Figure 4-148
b
a
b
